ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface

ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface
ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface

ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface

Szczegóły Produktu:
Place of Origin: CHINA
Nazwa handlowa: MTSCO
Orzecznictwo: ISO 9001 & PED & AD2000
Model Number: MTSCOHT43
Zapłata:
Minimum Order Quantity: negotiable
Cena: 4300-9800USD/TON
Packaging Details: Iron Case / Plywood Case
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 300 Tons / Month
Skontaktuj się teraz

Szczegóły informacji
Material: 300 Series Surface: Polished
Length: 8200mm Technology: Cold Rolled
Condition: Soft / Hard Inspection: 100%
High Light:

hydraulic tube

,

Hydraulic Seamless Tube

opis produktu

ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Tube





Product Description

Outer Diameter 3.18 -101.6mm
Wall Thickness 0.5 - 20mm
NPS 1/8"-24"
Schedule 5/5S,10/10S,20/20S,40/40S,80/80S,120/120S,160/160S
Material Grade 304/304L/316/316L/321/309S/310S/317L,etc
Standard ASTM A269, ASTM A312, etc
Application used in Fluid and Gas Transport, Structure and Machining,etc
Certificates ISO9001:2008, PED, BV
Process Method Cold Drawn/ Cold Rolled
Surface Finish Annealed/ Polished
Package Woven bag for each piece, then packed in seaworthy wooden cases
Delivery Time 20-60 Days after receiving the deposit (Normally according to the order quantity)
Price Item FOB, CIF or as negotiation
Payment T/T(30% in advance, 70% against the BL Copy) or as negotiation
Quality Requirement Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Main Market Europe, Middle East, Southeast Asia, South America, etc



Specification :











Size		 OD : 4.76 - 25.4mm
WT : 0.71 - 2.11mm
Length : >1000Meters
4.76 * 0.71mm / 4.76 * 0.89mm / 4.76 * 1.24mm
6 * 1mm / 6 * 1.5mm
6.35 * 0.71mm / 6.35 * 0.89mm / 6.35 * 1.24mm / 6.35 * 1.65mm
7.94 * 0.71mm / 7.94 * 0.89mm / 7.94 * 1.24mm / 7.94 * 1.65mm
9.53 * 0.71mm / 9.53 * 0.89mm / 9.53 * 1.24mm / 9.43 * 1.65mm
10 * 1mm / 10 * 1.5mm
12 * 1mm / 12 * 1.5mm / 12 * 2mm
12.7 * 0.71mm / 12.7 * 0.89mm / 12.7 * 1.24mm / 12.7 * 1.65mm / 12.7 * 2.11mm
14 * 1mm / 14 * 1.5mm / 14 * 2mm
15.88 * 0.89mm / 15.88 * 1.24mm / 15.88 * 1.65mm / 15.88 * 2.11mm
16 * 1mm / 16 * 1.5mm / 16 * 2mm
19.05 * 0.89mm / 19.05 * 1.24mm / 19.05 * 1.65mm / 19.05 * 2.11mm
25.4 * 0.89mm / 25.4 * 1.24mm / 25.4 * 1.65mm / 25.4 * 2.11mm



Chemical Composition:



  C(max) Si(max) Mn(max) P(max) S(max) Cr Ni Mo Ti
TP304/1.4301 0.080 1.00 2.00 0.045 0.030 18.0-20.0 8.0-10.5
TP304L/1.4307 0.035 1.00 2.00 0.045 0.030 18.0-20.0 8.0-12.0
TP304H/1.4948 0.04-0.10 1.00 2.00 0.045 0.030 18.0-20.0 8.0-12.0
TP316/1.4401 0.080 1.00 2.00 0.045 0.030 16.0-18.0 11.0-14.0 2.0-3.0
TP316L/1.4404 0.035 1.00 2.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0
TP316Ti/1.4571 0.080 1.00 2.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0 0.7>5x(C+N)
TP321/1.4541 0.080 1.00 2.00 0.045 0.030 17.0-19.0 9.0-12.0   0.7>5x(C+N)
TP317L/1.4449 0.080 1.00 2.00 0.045 0.030 18.0-20.0 11.0-14.0 3.0-4.0
TP347H/1.4912 0.04-0.10 1.00 2.00 0.045 0.030 17.0-19.0 9.0-13.0
TP309S/1.4833 0.080 1.00 2.00 0.045 0.030 22.0-24.0 12.0-15.0 0.75
TP310S/1.4845 0.080 1.00 2.00 0.045 0.030 24.0-26.0 19.0-22.0 0.75



MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .

Stainless steel seamless bright annealed tube’s final surface is polished and bright annealed . And the polished grade is includes 180 # , 320 # , 400 # , 600 # , 800 # . According to standard very strictly , tubes which produced by us always have correct OD and WT tolerance . At fluid industry , bright annealed hydraulic tubing has its own important position . Their useful life is higher than other tubing .



ASTM A269 Stainless Steel 6.35mm Small Diameter Hydraulic Pipe Polished Surface 0
