S30400 / S30403 ASME SA269 Stainless Steel Welded Super Long Coiled Tube For Cable Industry
Material Grade :
| American Standard |
TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L Etc |
| European Standard |
1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 Etc |
| German Standard |
X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc
|
Application
a) For fluid & gas transport
b) Structure & machining
c) Petrochemical
d) Environmental protection
e) Electricity
f) Instrument industry etc
Advantages
a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Price Item FOB , CFR , CIF or as negotiation
Payment TT, LC or as negotiation
Delivery Time 30 working days after received your deposit ( Normally according to the order quantity )
Package Iron case ; woven bag or as per customer’s requirement
Quality Requirement Mill Test Certificate will be supplied with shipment , Third Part Inspection is acceptable
Test NTD ( Ultrasonic test , Eddy Current test )
Mechanical Test ( Tension Test , Flaring Test , Flattening Test , Hardness Test , Hydraulic test )
Metal Test ( Metallographic Analysis , Impact Test - High / low temperature )
Chemical Analysis ( Photoelectric Emission Spectroscopic )
Main Market Europe , Middle East , Southeast Asia , South America etc
Chemical Composition :
| Material |
ASTM A269 Chemical Composition % Max |
| C |
Mn |
P |
S |
Si |
Cr |
Ni |
Mo |
N B |
Nb |
Ti |
| TP304 |
0.08 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-11.0 |
^ |
^ |
^. |
^ |
| TP304L |
0.035 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-12.0 |
^ |
^ |
^ |
^ |
| TP316 |
0.08 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
10.0-14.0 |
2.00-3.00 |
^ |
^ |
^ |
| TP316L |
0.035 D |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
10.0-15.0 |
2.00-3.00 |
^ |
^ |
^ |
| TP321 |
0.08 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-12.0 |
^ |
^ |
^ |
5C -0.70 |
| TP347 |
0.08 |
2 |
0.045 |
0.03 |
1 |
17.0-19.0 |
9.0-12.0 |
|
|
10C -1.10 |
^ |
| Size |
OD : 4.76 - 25.4mm |
| WT : 0.71 - 2.11mm |
| Length : >1000Meters |
| 4.76 * 0.71mm / 4.76 * 0.89mm / 4.76 * 1.24mm |
| 6 * 1mm / 6 * 1.5mm |
| 6.35 * 0.71mm / 6.35 * 0.89mm / 6.35 * 1.24mm / 6.35 * 1.65mm |
| 7.94 * 0.71mm / 7.94 * 0.89mm / 7.94 * 1.24mm / 7.94 * 1.65mm |
| 9.53 * 0.71mm / 9.53 * 0.89mm / 9.53 * 1.24mm / 9.43 * 1.65mm |
| 10 * 1mm / 10 * 1.5mm |
| 12 * 1mm / 12 * 1.5mm / 12 * 2mm |
| 12.7 * 0.71mm / 12.7 * 0.89mm / 12.7 * 1.24mm / 12.7 * 1.65mm / 12.7 * 2.11mm |
| 14 * 1mm / 14 * 1.5mm / 14 * 2mm |
| 15.88 * 0.89mm / 15.88 * 1.24mm / 15.88 * 1.65mm / 15.88 * 2.11mm |
| 16 * 1mm / 16 * 1.5mm / 16 * 2mm |
| 19.05 * 0.89mm / 19.05 * 1.24mm / 19.05 * 1.65mm / 19.05 * 2.11mm |
|
25.4 * 0.89mm / 25.4 * 1.24mm / 25.4 * 1.65mm / 25.4 * 2.11mm
|
